DI10P
DI 10P
Passive DI Box with Stereo Input / Summed Mono Output, Midas Transformer and Extended Dynamic Range
Product Features
-
Passive DI Box with stereo input and summed mono output
-
Custom-built Midas transformer for highest signal integrity
-
High headroom design offers superior sound quality
-
Passive design does not require any power supply
-
Stereo input on 1/8" TRS and RCA connectors
-
Fully adjustable level control for both channels
-
High quality Neutrik* XLR connector
-
Earth Lift switch eliminates ground loop problems
-
Fully transformer-isolated design ensures electrical separation
-
Ultra-low noise and ultra-linear system for highest signal integrity
-
Aluminium extrusion casing with protective rubber corners
-
Compact and rugged design
-
10-Year Warranty Program*
-
Designed and engineered in the U.K.
PRO DI DI 10P
Building on KLARK TEKNIK’s storied legacy of highest-quality direct injection devices, the DI 10P PRO DI offers the same high headroom, dynamic response and sonic clarity you have come to expect. DI 10P is ideal for interfacing MP3, CD players, keyboard or drum submixers, and a variety of other stereo sources to mixing consoles. A passive device, the DI 10P does not require any form of external power to complete its mission. Equipped with a custom-built MIDAS transformer, fully adjustable independent level controls for the stereo input channels, DI 10P is the perfect stereo to mono XLR solution for professional audio and multimedia applications.
MIDAS – The Legend in Sound Quality
Ever since its formation in the 1970s, MIDAS has had a long history of innovation and leadership in the world of audio mixing consoles. Employed by the most famous touring acts and installations world-wide, legendary MIDAS consoles such as the XL4 and Heritage H3000 quickly became industry standards.
MIDAS has earned their impeccable reputation due to their no-compromise approach for audio and build quality and in particular for their Award-winning products which are considered by industry experts as the industry’s best sounding designs. Building on this legacy, the XL8 and PRO Series of Live Mixing Systems continue this great heritage of Award-winning audio quality.
KLARK TEKNIK is proud to incorporate MIDAS designed transformers for the ultimate in high-quality audio reproduction in both live and studio environments. Find out more about MIDAS’ amazing legacy by visiting their extensive website.
High Headroom Design
A custom instrumentation-grade input circuit was designed for the DI 10P using advanced analogue design techniques to create the ideal input impedance match. This innovative approach provides an ultra low noise, low harmonic and phase distortion input stage with a ruler-flat frequency response that ranges from 10 Hz to 91 kHz (± 1 dB).
