HDL20A Line Array Module
0 - Yorum Yap
Marka
Garanti Süresi
24 Ay
135.191,87 TL
14.373,15 TL den başlayan taksitlerle!
SPECIFICATIONS
Acoustical specifications
FREQUENCY RESPONSE:
55 Hz ÷ 20000 Hz
MAX SPL @ 1M:
135 dB
HORIZONTAL COVERAGE ANGLE:
100°
VERTICAL COVERAGE ANGLE:
15°
Transducers
COMPRESSION DRIVER:
1 x 2.0'', 3.0'' v.c
WOOFER:
2 x 10'', 2.5'' v.c
Input/Output section
INPUT SIGNAL:
bal/unbal
INPUT CONNECTORS:
XLR
OUTPUT CONNECTORS:
XLR
INPUT SENSITIVITY:
-2 dBu/+4 dBu
Processor section
CROSSOVER FREQUENCIES:
800 Hz
PROTECTIONS:
Thermal, RMS
LIMITER:
Soft Limiter
CONTROLS:
Cluster, HF, High curving, Indoor
Power section
TOTAL POWER:
1400 W Peak, 700 W RMS
HIGH FREQUENCIES:
400 W Peak, 200 W RMS
LOW FREQUENCIES:
1000 W Peak, 500 W RMS
COOLING:
Convection
CONNECTIONS:
Powercon IN/OUT
Standard compliance
CE MARKING:
Yes
Physical specifications
CABINET/CASE MATERIAL:
PP Composite
HARDWARE:
Rigging flyware
HANDLES:
2 side, 2 back
GRILLE:
Steel
COLOR:
Black
Size
HEIGHT:
294 mm / 11.57 inches
WIDTH:
705 mm / 27.76 inches
DEPTH:
445 mm / 17.52 inches
WEIGHT:
30.2 kg / 66.58 lbs
Shipping informations
PACKAGE HEIGHT:
375 mm / 14.76 inches
PACKAGE WIDTH:
800 mm / 31.5 inches
PACKAGE DEPTH:
500 mm / 19.69 inches
PACKAGE WEIGHT:
33.2 kg / 73.19 lbs
