ISA 828MKII Mikrofon Preamp
0 - Yorum Yap
Marka
196.908,96 TL
20.934,70 TL den başlayan taksitlerle!
Specifications in detail
Mic inputs
- Gain Range0dB to +30dB (30-60 switch disabled) and +30dB to +60dB (30-60 switch enabled) in 10dB steps, with an additional +20dB of continuous trim
- Input ImpedanceLow = 600Ω, ISA 110 = 1400Ω, Med (Medium) = 2400Ω, High = 6800Ω
- Max. Input Level+7dBu, min gain, medium Z
- Frequency Response (20Hz - 20kHz)20Hz - 20kHz ±0.2dB, min gain, medium Z
- THD + N-91dB (0.0028%) @ -1dBr, min gain, medium Z
- EIN-123dBu 'A'-Weighted (typical)
- Signal-To-Noise Ratio122dB 'A'-Weighted (typical), medium Z
- Common-Mode Rejection Ratio997Hz CMRR: -93dB, min gain, medium Z
- Phantom Power+48V, independently switchable per channel
- High-Pass Filter75Hz knee frequency, 18dB/Octave, independently switchable per channel
- PhaseInverts the phases of the selected input
- Frequency Response (10Hz - 110kHz)10Hz - 110kHz ±1.5dB, min gain, medium Z
Line inputs
- Gain Range20dB to +10dB in 10dB steps, with an additional +20dB of continuous trim
- Input ImpedanceLow = 600Ω, ISA 110 = 1400Ω, Med (Medium) = 2400Ω, High = 6800Ω
- Max. Input Level+25dBu, min gain, low Z
- Frequency Response (20Hz - 20kHz)20Hz - 20kHz ±0.1dB, min gain, low Z
- THD + N-91dB (0.0028%) @ -1dBr, min gain, low Z
- Signal-To-Noise Ratio122dB 'A'-Weighted (typical), min gain, low Z
- Frequency Response (10Hz - 122kHz)10Hz - 122kHz ±3dB, min gain, low Z
Instrument inputs
- Gain Range+10dB to +40dB with continuous gain using trim pot
Front panel connectivity
- Channel Count2 Channels In
- Instrument Inputs4 x 1/4" jack inputs
- Instrument Inputs4 x 1/4" jack inputs
Rear panel connectivity
- Mic InputsInput: 8 x Female XLR
Line level
- Channel Count8 In and 8 Out
- Input8 x 1/4" jack inputs
- Output1 x DB-25 connectors (AES59)
Inserts
- Channel Count8 In
- Input1 x DB-25 connectors (AES59)
Digital card slot
- Compatible CardISA ADN8
Front panel indicators
- Control Functions16 x Pots (Gain and Trim). 60 Switches (On/Off Switch, 30-60 Gain, +48V, Phase, HPF, Insert, Z In, Input, Meters Pre A-D, Clock Select and Ext. Word Clock)
Rear panel indicators
- Control Functions1 x Pot (Meter Trim
